Quoizel DW8603C Downtown - Manual

PACKAGE CONTENTS
INSTRUCTION SHEET IS DW8603
: -
STYLE NUMBER DW8603C
:
ISSUED 09-2009 Revised 2013-08-23
1 OF 3
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Part
A
E
C
G
B
F
D
H
I
J
K
Description
Crossbar
Green Ground Screw
Nipple
Lock Washer
Hex Nut
Lock Ball
Bulb Shield
Bulb
Fixture Body
Shade
Quantity
1pc
1pc
1pc
1pc
1pc
1pc
3pcs
3pcs
3pcs
3pcs
1pc
3pcs
K
Socket Collar
Steel Collar
A
B
C
D
E
F
G
H
J
I
WARNINGS AND CAUTIONS
!
PREPARATION
WARNING:
Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by
switching off the circuit breaker or removing the fuse.
CAUTION:
These instructions are provided for your safety. It is very important that they are read completely before
the installation of your fixture. We strongly recommend that a professional electrician install the fixture.
Disconnect fixture from the power source before replacing the bulb(s), making sure the bulb(s) had
sufficient time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may
result.
Do not touch the bulb with bare hands use a cloth or glove.
●
●
●
●
Before beginning installation of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement part.
Estimated Assembly Time : 20 30 minutes
Tools Required for Assembly (not included) : Flathead Screwdriver Phillips Screwdriver, Pliers,
Electrical Tape, Wire Cutters, Safety Glasses & 3, 60 Watt, Frosted JCD G9 Bulbs.
Helpful Tools (not included) : Wire Strippers.
●
●
●
●
-
,
L
L
