Quoizel BWR8602BN Bower - Manual (Page 2)

2of2
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2014 QuoizelInc.
BWR8602BN
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2 "
REPLACEMENT PART DESCRIPTION REQ. NO.
FINISH: BRUSHED NICKEL
Figure 5
STEP 5 Install Fixture Body -
A. Carefully tuck all wires into the outlet
box and position the backplate of
Fixture Body (A) over the outlet box.
Align the holes in the backplate with
the mounting screws. Place caulk (not
supplied) into the previously removed
mounting balls and then attach Fixture
Body (A) using the mounting balls.
Hand tighten until snug.
Figure 6
STEP 6 Install Bulb -
A. This fixture uses standard bulb with a
medium screw base. Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to
use. Enjoy!
Bulb
AA
A
Mounting
Screw
Mounting
Ball
Socket
March2014
(2) 100W
Bulbs
(Not Supplied)
Medium
Base
9.5”
5.5”
5”Dia.
7”
13”
1 G3655SH GLASS OPAL ETCHED 2
1
