Installation instructions, Step 4, Step 5 – Quoizel TY8501AN Taylor User Manual
Page 3
INSTALLATION INSTRUCTIONS
3 OF 3
STYLE NUMBER: TY8501AN, TY8501WT
STEP 4:
a. Place the Shade and the Steel Collar over the Socket
as shown. Secure by threading the Socket Collar onto
the Socket. Hand-tighten until snug.
Shade
Socket
STEP 5:
a. Install the correct Bulb referring to fixture markings and/or labels for maximum wattage.
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
Steel Collar
Socket Collar
