INSTALLATION INSTRUCTIONS
STEP 4:
a. Place the Shade and the Steel Collar over the Socket
as shown. Secure by threading the Socket Collar onto
the Socket. Hand-tighten until snug.
Steel Collar
Socket
Socket Collar
Shade
STEP 5:
a. Install the correct bulb referring to fixture markings and/or labels for maximum wattage.
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
STYLE NUMBER: SPH8701PN, SPH8701BN
