11.3 Physical Characteristics Bluetooth Cradle
Weight Approx 150 gr.
Material ABS Plastic
Connector RJ 45C 10Pins
Dimension 129.9mm x 120mm x 71.4mm
11.4 Operational
Light Source
Visible Red light 650nm
Scan rate (Linear mode) 200scans/sec auto adaptive
(Area mode) 56 Images/sec auto adaptive
Optical resolution 752 x 480 pixels
256 gray levels.
Scan Angle 38° horizontal,
25° vertical
Interface RS232, USB (HID or
Virtual Com) or PS/2 KBW
(V-1020BT series only)
V-1020 Indicators (led) Green = good read
V-1020BT Indicators (led) Green = good read
Red = low battery
Blue = Bluetooth function
11.5 Electrical Characteristics
(V-1020)
Operation Voltage 5 VDC ±5%
Current operating
450mA (max) @ 5VDC
Current standby 37mA typical @ 5VDC
AC Transformer 5.2 VDC @ 650 mA/
Input AC 100-240V
