20
1/ AL-4147-2
For better EMI performance and easier integration, the AL-4147-2 provides high ground isolation between its input
signal circuitry, control circuit and power stage. It also incorporates a highly modular design allowing for easy
maintainability. This model is suited to applications requiring remote separation of the PCU.
2/
AL-4107-2-6A Models
These models represent ORBIT/FR’s third-generation of heavy duty PCUs incorporating state-of-the-art control
engineering technology, including four-quadrant Pulse Width Modulation (PWM) techniques and sophisticated,
fail-safe protective circuitry. They offer precision DC servo control and superior acceleration and deceleration
profi les.
ORDERING INFORMATION
• AL-4147-2 Power Control Unit (PCU), 6 Axis
• AL-4107-2-6A Power Control Unit (PCU), 6 Axis
• AL-4107-2-6A-4A5 Power Control Unit (PCU), 6 Axis
front panel
> Controls:
„ AC Power On/Off
„ Emergency Stop (E-Stop)
technical notes
„ AL-4147-2 is functionally compatible with previous
generation model AL-4146-2, with limitations
and enhancements (consult your local factory sales
representative for specifi c compatibility needs).
supplied accessories
> CD-ROM Documentation Set:
„ User Manual (Installation, Setup, Operation)
> AL-4147-2:
„ AC Power Cord, IEC-320 (F) to Plug
> AL-4107 Models:
„ Unterminated AC Power Cord (3 Phase)
„ AL-4146-2L Local Control Unit (LCU) w/ Interconnect
Cable (10 m standard)
options
> All Models:
† Opt. 101 - Additional Manual Set
† Opt. 102 - International Localization (Specify Country
& Voltage)
> AL-4107 Models:
† Opt. 001 - Outdoor Enclosure for AL-4107-2-6A PCU &
AL-4107-2-1 PSU. 19 Inch EIA. Includes front
door, rear cable input, AC outlet strip, heater, and
cooling fans. Rated for indirect outdoor exposure.
Suitable for outdoor silos and base risers.
† Opt. 002 - Interface Unit, S/A 4180 Format
† Optional „ Standard
