VICI Two Position Microelectric - Manual (Page 2)

2
2 POSITION ACTUATOR
CONTROL MODULE
A B
POSITION
A
POSITION
B
POSITION
TO 110 OR 220 VAC
(User must supply other
line cord configurations)
POWER SUPPLY
P/N PS24VDC-CE
LINE CORD (IEC-320)
P/N I-W-17600
BLACK / WHITE STRIPE
BLACK
GND
+24-28 VDC
TO
EXTERNAL
CONTROL
SYSTEM
DIGITAL INPUT/
OUTPUT CABLE
P/N I-22537
PIN 1
OPTIONAL
INPUT POWER CABLE
P/N I-22535-CE
MOTOR DRIVER
OUTPUT CABLE
P/N I-22645
PIN 1
MOTOR/GEARBOX
ASSEMBLY
P/N EQMA (Highest speed)
EHMA (High speed and
Medium torque)
EDMA (High torque
ETMA (Highest torque) MANUAL
CONTROLLER
(Use optional)
P/N I-22689
PIN 1
CLAMP
SCREW
MANUAL CONTROLLER CABLE
P/N I-22537-01
PIN 1 PIN 1
P/N:
EQCA-CE (Highest speed)
EHCA-CE (High speed)
EPCA-CE (Medium torque)
EDCA-CE (High torque)
ETCA-CE (Highest torque)
POSITION
INDICATOR
LIGHTS
OPTIONAL
SERIAL PORT
(RS-232) CABLE
P/N I-22697
DB-9
CONNECTOR
(FEMALE)
TO COMPUTER
Figure 1: Actuator and controller connections
Valco Instruments Co. Inc.
CLAMP
RING
MOUNTING
BRACKET
P/N I-22596
