1.2 Product Numbers and Specifications
Product Numbers: ITC10X
X corresponding to
399 for 0°C to 399°C range
999 for 0°C to 999°C range
Example:
ITC10399: ITC, 1000 watts maximum heater power, 0°C to 399°C range
Sensor Requirement Thermocouple; Type K
Range 0° to 390°C, or 0° to 999°C, as ordered
Absolute Accuracy
±
.5% of full scale
Repeatability .5°C at constant ambient
Sensititivity to Ambient Changes .05°C per °C change
Operating Ambient 10° to 50°C
Switched AC Power 1000 watts;
zero-crossing error: 5V AC max.
Proportioning Bandwidth
±
3°C
Proportioning Frequency 2 Hz
Setpoint 1° C increments; push button selection
Max. Power Input Requirement 10.0 amps at 117 VAC
Power Attenuation 0 to 90% in 10% increments
Physical Dimensions 2.4" x 8.3" x 5.9"; weight 1 lb. 14.4 oz.
Visual Indicators
•
Power On (PWR) - illuminated whenever the instrument is plugged
into a source of 120V AC, and the PWR switch is in the ON position
•
H ea t er O n ( HT R ) - i l lu m i nat ed w henever t he c ont r ol ler a ppl ies
power to the heater
•
Thermocouple Fault (TCPL) - illuminates whenever thermocouple sensor
opens. (If a sensor failure is detected, heater power is automatically
interrupted, and the HTR indicator will remain OFF.)
