Unitec ReachFree ID for Wash Select II User Manual
Page 3

R E A C H F R E E I D
Document Number:
RFID1001
iii
Document Name:
Unitec RFID Field Retrofit Installation Guide
Table of Contents
1 Introduction ......................................................................................................... 1
2 Software Requirements ...................................................................................... 1
3 Site Planning ....................................................................................................... 1
4 Parts Checklist .................................................................................................... 1
5 Installation Procedures ...................................................................................... 2
5.1 Install the Mounting Pole (Optional) ............................................................. 2
5.2 Install the Reader ......................................................................................... 5
5.3 Site Installation ............................................................................................. 7
5.4 Connector Wiring ......................................................................................... 9
5.5 Mount RFID Board and Connect Cables in WSII ....................................... 10
6 RFID Tags .......................................................................................................... 11
7 Program the WashPay Server .......................................................................... 12
8 Troubleshooting ................................................................................................ 12
