9 IBC15-GD-0512-EN
PROBLEM POSSIBLE CAUSES ACTION
2. External Fuses
blown
Reverse Battery Hook-Up Correct hook-up and replace Fuses with same type
and rating
3. Charger cycles
on & off
Compartment gets too hot Check air flow to the charger
Improve Ventilation to the compartment
4. Low Output Excessive Load for Charger Reduce load requirements or install larger charger
Input Voltage not between 105-130 VAC Correct input supply voltage
Bad Battery Cell(s) Replace battery
5. Intermittent or no
Output on
Generator, but
works on Shore Power
Unit has shutdown due to over voltage. Add another load to the generator, this may reduce
the “spikes” to an acceptable level
Some generators provides excessive
voltage spikes on the AC power output,
this may cause the over voltage protection
to shut the unit down Contact generator manufacturer for possible defect
in the generator
6 Input / Output Specifications
Input 105-130 VAC 60 Hz 3.5A
Output 13.6 VDC 15 Amps
Dimensions 9.7 x 6.7 x 3.4 (in.)
Weight 5.0lbs
