MAXIM 50E/U PUMP OPERATION / MAINTENANCE MANUAL PAGE 21

Wrap each transfer tube with 3 wraps of Teflon tape and reinstall into the
head ports using latex gloves for added grip. Leave a protrusion height of 2”
for each transfer tube.

Position control base on mounting base, slide base forward, use locking lever
to secure.

Ensure that the ferrule of the quick grip nut is inserted into the transfer tube
port of the base. Place the gripper seal on top of the ferrule with the tapered
end facing up.

Loosely attach quick grip nuts to transfer tube ports on control base taking
care not to dislocate the ferrule and gripper seal.

Install pump onto control base by inserting transfer tubes in pump into quick
grip nuts on control base.

To secure pump to control base, tighten quick grip nuts one (1) full turn past
hand tight using 13/16” wrench.

Reinstall seals, optic probes (Probes included with E Model only), and optic
probe caps (E Model only)
into heads using the 3/4” slotted pin tool. (Do not
twist optic fibers as they could be damaged.)

Reconnect both air supply and fluid lines.
