MAXIM 50E/U PUMP OPERATION / MAINTENANCE MANUAL
Figure 3-1: Pressure & Capacity Chart
NOTE: Test information is based on specific conditions and limited sampling.
Use for general reference only.
Figure 3-2: Pressure vs. Fluid Temperature Chart
Recommended Maximum Pump Operating Pressure
NOTE:
1. This graph is not representative of all operating conditions -
customer’s
specific application results may vary.
2. Be sure that fittings and tubing used are capable of these operating
conditions.
