MAXIM 50D PUMP OPERATION / MAINTENANCE MANUAL PAGE 3
1 INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.
The following items should be included within the shipping container:
Qty Item Description
1 M50D Maxim 50D Pump
1 MM50D Operation/Maintenance Manual
1.2 UTILITIES / HOOK-UP
It is recommended that the pump be positioned within 15

from level to maintain
self-priming ability and pumping efficiency. Allow sufficient room for tubing
connectors. The pump mounts on a quick-change base for easy installation.
The pump has an exhaust location on the backside of the base. The exhaust
location requires 1/2” (12mm) minimum clearance behind the control base. Care
should be taken to elevate the pump whenever possible to help prevent flooding
these ports when the pump is located in a wet bench plenum. For remote
exhaust connection see Section 0.
Air Inlet: 1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).
Fluid Ports: Inlet/Outlet Fluid Fittings and Surge Suppressor require torqueing
during pump installation. See Section 2 for hook- up diagram and
torque values.
Air Supply: 20-80 psig (1.4 – 5.4 bar) clean dry air or nitrogen (See
Performance Charts, Section 3.1.)
