MAXIM 50D PUMP OPERATION / MAINTENANCE MANUAL PAGE 13
4.2 RECOMMENDED SPARE PARTS
KR50D-00-B Spares Rebuild Kit, which includes:
Part No Qty Description
KM50D-00-B 1 Maintenance Kit
Includes: (2)
(1)
(2)
(1)
(2) AK123
AK205
L0197
L0145
AK127 Distribution Pilot Assy
Muffler Assembly
Detent Leg
Detent Ring
Assembly, Muffler
KD50D-00-A 1 Diaphragm Kit
Includes: (2)
(2) 1700C0047
AK139 Diaphragm
Wear Resist Diaphragm
98001415 4 Check Ball, PTFE
98002334 4 O-ring, -312 PTFE
98003079 2 Shaft Seal
AK004 1 Shaft
AK153 2 Check Cap Seal
In critical applications, a spare pump is recommended to minimize possible down
time during service intervals.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KT50-00-B Tool Kit, which includes:
Part No Qty Description
98003108 1 Torque Wrench, 30- 150 ft/lb., 1/2” Drive
98003150 1 Tool Case, w/Foam, M50
98003305 1 Handle, Soc, 1/4" Drive
98003306 1 Wrench, Adj, 15/16"
T0126 1 Tool, Shaft Insert
T0129 1 Tool, Strap Wrench
T0132 1 Rebuild Fixture
T0144 1 Tool, Wedge, Head Removal, Cleaning Tool
T0146 1 Tool, Pin, 3/4x1/4 Drive
T0147 1 Tool, Pin, 1x1/4 Drive
T0148 1 Tool, Pin, 1/2x1/4 Drive
T0149 1 Tool, Pin, Optic Cap, 3/4
