MAGNUM 620R PUMP OPERATION / MAINTENANCE MANUAL

PAGE 3

1

INSTALLATION

1.1 UNPACKING

After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.

The following items should be included within the shipping container:

Qty

Item

Description

1

620

Magnum 620 Pump

1

M620R

Operation/Maintenance Manual

1.2 UTILITIES / HOOK-UP

It is recommended that the pump be positioned within 15

from level to maintain

self-priming ability and pumping efficiency. Allow sufficient room for tubing
connectors. The pump mounts on a quick-change base for easy installation.

The pump has an exhaust location on the backside of the master head. The
exhaust location requires 1/2” (12mm) minimum clearance behind the master
head. Care should be taken to prevent flooding the exhaust port when the pump
is located in a wet bench plenum. For remote exhaust connection see Section 0.

Air Inlet:

1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).

Air Supply:

20-80 psig (1.4

– 5.5 bar) clean dry air or nitrogen (see

Performance Charts, Section 3.1).

Fluid Ports:

1” NPSM – additional adaptor port options available.
Inlet/Outlet adaptor fittings and Surge Suppressor require
torqueing during pump installation. See Section 2 for hook-up
diagram and torque values.
