TerraLUX TLM-R16C Product Specification (05/03/2013) Subject to change without notice 4
TESTS AND CERTIFICATIONS
Product Safety Certifications • UL Standard 1993: Self Ballasted Lamps and Lamp Adaptors
• UL Standard 8750: LED Light Sources for Use In Lighting Products
• CSA C22.2 No. 1993-09: Self Ballasted Lamps and Lamp Adaptors
Radio Frequency Emissions •FCC Part 15, Unintentional Radiators Class B.
Sec 107, Conducted Emissions - 0.15MHz – 30MHz
Sec 109, Radiated Emissions - 30 MHz – 8000MHz
•Industry Canada Notice ICES-003: Class B Digital Apparatus
Reduction of Hazardous Substances
(RoHS) • European Council Directive 2002/95/EC, (including amendments 2005/618/EC,
2005/717/EC and 2005/747/EC) on the restriction of certain hazardous substances in
electrical and electronic equipment.
Electro-Static Discharge •± 4kV and ± 6kV contact discharge
•±8kV and ± 10kV air gap discharges
Power Factor 0.92 @ 12 V AC (high mode)
Shock Operating - 82 G peak, 2 ms; Half sine, 1 shock per second 20 shocks per axis, both di-
rections – total 120 shocks
Non-Operating - 120 G peak., 2 ms, Half sine, 1 shock/second, 3 shocks per axis, both
directions – total of 18 shocks
40 G Faired Square wave w/ velocity change of 62 in/sec. 1 shock per axis, both direc-
tions – total of 6 shocks
Drop Test - Drop from a distance of 1 meter onto a non-resilient test floor. The test
surfaces shall be the face, two opposing sides, the base, and two opposing top corners.
Operation is to be checked after each impact.
Drop Test
Vibration Operating - Random PSD Spectrum G, 1.0G RMS, 10-2000 Hz. 30 minutes per axis 3-
500 Hz., 0.50 g peak, swept sine @ ½ octave/min per axis
Non-Operating - Random PSD, 5 G RMS, 15 minutes per axis
5-500-5 Hz, 1.0 g peak, Swept Sine @ ½ Octave per minute, per axis.
Shipping / Transit International Safe Transit Association (ISTA) Project 2A.
Operating Temperature -40°C to +55°C, 0 to 95% R.H. / 157 hr.
Storage Temperature -40°C to +85°C / 60 hr. followed by 20°C to 85°C, 5 to 95% R.H. / 80 hr.
Lumen Maintenance L70 =60,000hr per IES TM-21-11 (Based on LED Manufacturer’s measurement per IES
LM-80-08 @ 10.000hrs).
Long Term Operation MBTF = 62,000 hours
Input Voltage Range 9.6—14.4 V AC / 12—14.4 V DC
Dimming Meets NEMA Standards Publication SSL 6-2010, Solid State Lighting for Incandescent
Replacement—Dimming. Specifically the upper and lower limits of light output vs. dim-
mer position and that the dimming is strictly monotonic. When connected to a variety
of electronic dimmer/transformer combinations fell within the upper and lower limits of
the light output curve defined by NEMA
