HX-3 User Guide and Technical Information
4
Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Front Panel Controls
1 2 3 4 5
1. Stereo/Mono Switch
Sums stereo and two-channel audio
program to mono for mono headphone
monitoring.
2. Headphone Gain
Controls Volume of each headphone
output.
3. Headphone Peak LED
Illuminates 3 dB before clipping to indi-
cate onset of headphone distortion.
4. POWER LED
Bi-color LED illuminates green when
the unit is powered and changes to red
when approximately four hours of bat-
tery life remain.
5. POWER Switch
Powers the unit from either Internal bat-
teries, or External DC. Seamless switcho-
ver from each power source.
