SONIQ QV263L User Manual
Page 10
Connect to the power cord.
Connect an HDMI signal of your HDMI device.
Connect PC audio output of your personal computer.
Connect the PC VGA signal output of your personal computer.
Connect the component video output of your AV devices here.
Audio (Audio input, L/R): Connect the audio output of your AV
device here.
Connect composite Audio and Video output of your AV device.
Connect S-Video output of your AV device.
PHONE
AC IN
USB
HDMI1/2
PC AUDIO IN
VGA
YPbPr1/YPbPr2
VIDEO
S-VIDEO
Connect to external antenna.
8
11
Connect the audio amplifier.
COAX
L OUT
R OUT
V OUT
L IN
R IN
V IN
COAX
Connect to Portable USB Memory
.
device
