Layout of controls and other components – SONIQ MC9 User Manual
Page 4

3
38. SPEAKER TERMINALS
39. BEAT CUT/FM MONO/STEREO
40. MAIN SYSTEM POWER SWITCH
41. VOLTAGE SELECTOR (110/220 V - OPTIONAL)
42. MAINS POWER CORD
32. CASSETTE KNOB DOOR
33. MEMORY BACKUP BATTERY COMPARTMENT COVER
34. FM ANTENNA
35. FM ANTENNA TERMINAL (75 OHM - OPTIONAL)
36. AM ANTENNA TERMINAL (OPTIONAL)
37. RESET BUTTON
33
32
35
34
36
37
38
39
40
41
42
LAYOUT OF CONTROLS AND OTHER COMPONENTS
