FRAME
NOTE: Both illustrations are of the left, or drivers
side, of the vehicle. Reverse any orientations when
assembling and installing the right, or passenger, side
of the vehicle.
110/70 AIR SPRING
FIGURE "A"
3/8” -1 6 x 4”
HEX BOLT
3/8” SPECIAL
WASHER
3 /8” -16
FLANGED
LOCK NUT
HOLES
TO
BE
DRILLED
7/16"
WHE
EL
FR
ONT
3/8” -16 x 4”
HEX BOLT
AIR LINE
3/8” - 16 X 3/4”
FLANGED
HEX BOLT
LOWER BRACKET
3/8”-16 x 4.-1/2”
CARRIAGE BOLT
3/8”-16 x 4-1/2”
CARRIAGE BOLT
1/2” BRACKET STRAP
AXLE
3/8” - 16
FLANGED
LOCK NUT
L EAF SPRING STACK
1/2” BRACKET STRAP
UPPER
BRACKET
AIR FITTING
3/8” - 16 x 3/4”
FLANGED
HEX BOLT
KIT ASSEMBL
Y
2379
KIT TO FRAME ASSEMBLY
