Rite-Ride 2162 - Manual (Page 2)

3/8" -16 X 1 1/2"
HEX BOLTS
NOTE: Both illustrations are of the right, or
passenger’s side, of the vehicle. Reverse any
orientations when assembling and installing the left,
or drivers, side of the vehicle.
UPPER BRACKET
(21-5202)
2162
KIT TO FRAME ASSEMBLY
(1/2 TON VEHICLES)
FIGURE "A"
AIR FITTING
LOWER BRACKET
(21-5203)
AIR SPRING
110/70 (9002)
3/8" - 16
FLANGED
HEX BOLTS
3/8" - 16 FLANGED
HEX BOLT
LEAF SPRING
3/8" -16
x 4 1/2"
CARRIAGE
BOLT
FRAME
AIR
LINE
AXLE
ASSEMBLED AIR
SPRING UNIT
3/8" -16 FLANGE
LOCK NUTS
LARGE FLAT
WASHERS
HOL
ES TO
BE DRILLED 7/16"
K
I
T
A
S
S
E
M
B
L
Y
3/8" -16 X 1 1/2"
HEX BOLTS
LARGE FLAT
WASHERS
DISK
(21-5204)
BRACKET
STRAP (5086)
3/8" -16 FLANGE
LOCK NUTS
HOOK
CROSS MEMBER
REMOVE
NOTE: Short box pickups may have an
alignment bracket that must be removed
in order for the upper bracket in the
Sport-Rite kit to fit properly. Remove
this bracket flush with the cross member.
Please take necessary safety precautions
when removing this bracket.
DODGE SHORT BOX ONLY
(1/2 TON VEHICLES)
REAR
WHEEL
FRAME
