Casio 2163-2 User Manual
Module no. 2163
2163-1
Module No. 2163
GENERAL GUIDE
•
If the contents of the display seem to be continually changing, see “AUTO DISPLAY FUNCTION” for information on how to stop it.
•
Press
C
C
C
C
C
to change from mode to mode.
•
In any mode, press
L
L
L
L
L
to illuminate the display for about two seconds.
* If you hold down
L
L
L
L
L
, part of the segment indicator in the upper right corner of the display flashes.
Caution
•
The backlight of this watch employs an electro-luminescent (EL) light, which loses its illuminating power after very long term use.
•
Frequent use of the backlight shortens the battery life.
•
The watch emits an audible sound whenever the display is illuminated. This is because the EL light vibrates slightly when lit. It does not indicate malfunction of the watch.
TIMEKEEPING MODE
This watch lets you select any two of 40 cities (TIME 1, TIME 2) as basic Timekeep-
ing Mode times. Hold down
D
D
D
D
D
to toggle the Timekeeping Mode between TIME 1 and
TIME 2.
•
You can display either the city code or year. Press
A
A
A
A
A
to toggle between display of
the city code and year.
To set the time and date
Setting the time and date for either of the basic times (TIME 1 or TIME 2) automati-
cally adjusts the settings of the other basic time.
•
You can turn daylight saving time (DST) on and off independently for TIME 1 and
TIME 2.
1. While in the Timekeeping Mode, hold down
A
A
A
A
A
until the City Code flashes on the
display.
2. Press
C
C
C
C
C
to change the selection (flashing) in the following sequence.
3. While the seconds setting is selected (flashing), press
D
D
D
D
D
to reset it to 00. If you
press
D
D
D
D
D
while the seconds setting is in the range of 30 to 59, the seconds are reset
to 00 and 1 is added to the minutes. If the seconds setting is in the range of 00 to
29, the minutes count is unchanged.
•
While City Code setting is selected (flashing), press
D
D
D
D
D
or
B
B
B
B
B
to scroll through the
City Code. (For full information on City Code, see the CITY CODE TABLE.)
•
While the DST setting is selected, press
D
D
D
D
D
to toggle it ON and OFF.
•
While the 12/24-hour format setting is selected, press
D
D
D
D
D
to toggle it between 12
and 24.
•
While any other setting is selected (flashing), press
D
D
D
D
D
to increase it or
B
B
B
B
B
to de-
crease it.
•
Holding down either button changes the setting at high speed.
4. After you set the time and date, press
A
A
A
A
A
to return to the Timekeeping Mode.
•
The day of the week is automatically set in accordance with the date.
•
The date can be set within the range of January 1, 1995 to December 31, 2039.
•
If you do not operate any button for a few minutes while a setting is flashing, the
flashing stops and the watch goes back to the Timekeeping Mode automatically.
FILE MODE
Caution
The following causes all data stored in memory to be deleted. Be sure to
always keep separate written copies of all important data.
•
Malfunction or repairs
•
Dead battery
•
Battery replacement
In no event will CASIO be liable for loss of data or any damages arising out of
such loss.
The File Mode lets you store up to 30 pairs of
name and telephone number data. The name
can be up to 8 characters long and the num-
ber up to 12 digits. Data is automatically sort-
ed into alphabetical order based on the name
data. You can recall data by scrolling through
it on the display.
•
If you do not operate any button for a few
minutes while in the File Mode, the watch
automatically goes back to the Timekeeping
Mode.
To input File data
1. In the File Mode, press
B
B
B
B
B
or
D
D
D
D
D
until the new
data display appears.
•
If the message “FULL” appears on the display, it
means that memory is full. To store more data,
you will first have to delete some of the data.
2. Hold down
A
A
A
A
A
until the flashing cursor appears
on the name area.
3. Use
B
B
B
B
B
or
D
D
D
D
D
to input a character at the cursor
position. The character changes in the following
sequence. Holding down either button changes
the character at high speed.
4. After you select the character you want, press
C
C
C
C
C
to advance the cursor to the right.
•
Repeat steps 3 and 4 until you complete name input.
•
You can input up to 8 characters in the name area.
5. After the name input is through, use
C
C
C
C
C
to move the cursor to the number area.
6. While the cursor is in the number area, use
B
B
B
B
B
or
D
D
D
D
D
to input a number you want.
The character changes in the following sequence. Holding down either button
changes the character at high speed.
7. After you select the character you want, press
C
C
C
C
C
to advance the cursor to the right.
•
Repeat steps 6 and 7 until you complete number input.
8. After inputting the data you want, press
A
A
A
A
A
to store it into memory.
•
The message SORT appears on the display for a few seconds.
•
The name area shows only 5 characters, but automatically scrolls from right to left
to show all of the characters that make up the text.
To scroll through File data
In the normal File Mode (when the display is not flashing), press
D
D
D
D
D
to scroll forward
or
B
B
B
B
B
to scroll backward through stored data.
•
The data item that is displayed when you exit the File Mode will be the first data to
appear when you enter the File Mode again.
To edit File data
1. In the File Mode, use
B
B
B
B
B
and
D
D
D
D
D
to scroll through the data items and display the one
you want to edit.
2. Hold down
A
A
A
A
A
until the flashing cursor appears on the display.
3. Use
C
C
C
C
C
to move the cursor to the character you want to change.
4. Use
B
B
B
B
B
or
D
D
D
D
D
to select the character you want.
•
For details, see “To input File data” (steps 3 through 4 for name input, or 6 through
7 for number).
5. After editing the data, press
A
A
A
A
A
to store it.
To delete File data
1. In the File Mode, use
B
B
B
B
B
and
D
D
D
D
D
to scroll through the data items and display the one
you want to delete.
2. Hold down
A
A
A
A
A
until the flashing cursor appears on the display.
3. Press
B
B
B
B
B
and
D
D
D
D
D
at the same time to delete the data item.
•
The message CLR (clear) appears on the display for a few seconds.
•
At this time the cursor appears on the display ready for input.
4. Input data or press
A
A
A
A
A
to return to the File Mode.
ALARM MODE
When the Daily Alarm is turned on, the alarm
sounds for 20 seconds at the preset time each
day. Press any button to stop the alarm after it
starts to sound. When the Hourly Time Signal is
turned on, the watch beeps every hour on the hour.
•
The alarm sounds when the time selected for
basic timekeeping in the Timekeeping Mode
(TIME 1 or TIME 2) matches the alarm time you
set.
To set the alarm time
1. Hold down
A
A
A
A
A
while in the Alarm Mode. The hour
digits flash on the display because they are se-
lected. At this time the Daily Alarm is turned on
automatically.
2. Press
C
C
C
C
C
to change the selection in the following
sequence.
Stopwatch Mode
Timekeeping Mode
File Mode
Alarm Mode
Hour
Minutes
– (Hyphen)
0 to 9
(Space)
Press .
Press .
A to Z
0 to 9
(Space)
–
•
•
•
/
Press .
Press .
TIME 1
Press
A
A
A
A
A
.
Press
A
A
A
A
A
.
Hold down
D
D
D
D
D
.
Hold down
D
D
D
D
D
.
Month-Day
Day of week
City code
Year
DST on
indicator
TIME 2
Name area
Mode indicator
Number
area
Remaining
memory
New data display
Current time
Mode
indicator
Minutes
Hourly time
signal on
indicator
Alarm on
indicator
PM
indicator
Hour
Seconds
DST
City Code
Hour
Minutes
Day
Month
Year
12/24-Hour
Format
