7 REVEL Concerta F12
Owner’s Manual
Unpacking
(continued)
2. Without allowing the top flaps to close,
stand the packing carton upside-down
as shown in Figure 1 (above).
3. Lift the packing carton off of the
loudspeaker as shown in Figure 2
(above). Use caution to avoid dam-
aging the loudspeaker cabinet. At
this point, the loudspeaker will be
upside-down.
4. Remove the bottom pad and the
microfoam sheet. These items are
identified in Figure 3 (right).
Note
If the F12 is to be placed on a carpeted
floor, install the spikes while the loud-
speaker is upside-down. Refer to the
Feet and Optional Spikes section that
begins on page 11 for instructions.
5. Grasping the sides of the cabinet, place
the F12 on its side. Then, place the F12
in the upright position.
6. When the F12 is in the upright position,
remove the Owner’s Manual, Warranty
Card and Spikes.
7. Remove the top pad and microfoam
sheet.
1
2
TOP
3
Figure 1: Unpacking the F12 Figure 2: Lifting the Carton
Figure 3: Packing Materials
