Page 26
26
SECTION
FIVE
Connecting the Phantom II
to Your System
This section describes Phantom II Preamplifier connections.
Input and Output Connections
Krell recommends using its proprietary Krell CAST system for unparalleled sonic
performance for connections between the Phantom II preamplifier and other
CAST-equipped components. Krell CAST uses flexible interconnecting cables that
can be drawn through tight spaces and concealed.
The Phantom II also offers balanced operation. The circuitry and connections
associated with balanced operation not only can minimize sonic loss but also are
immune to induced noise, especially for installations using long cables.
XLR Pin Configuration
Pin 1
Ground
Pin 2
Non-inverting (0
O
)
Pin 3
Inverting (180
O
)
Inputs and outputs are located on the Phantom II back panels. Maintain the cor-
rect left/right orientation, when hooking up your system.
