Kino Flo Double Fixture Dimensions
Barndoor Weight
Fixture Style Length Width Depth Width w/Lamps
15” Double 18” 7.5” 3.5” 6” 3.5 lbs
2ft Double 27” 7.5” 3.5” 6” 4.7 lbs
4ft Double 52” 7.5” 3.5” 6” 7.7 lbs
Kino Flo Single Fixture Dimensions
Barndoor Weight
Fixture Style Length Width Depth Width w/Lamps
15” Single 18” 4.5” 3.5” 3.5” 2 lbs
2ft Single 27” 4.5” 3.5” 3.5” 2.7lbs
4ft Single 52” 4.5” 3.5” 3.5” 4.3lbs
Kino Flo Lamp w/ Harness Dimensions
Lamp Type Length Width
15” Medium Bi-Pin 15.5” 1.5”
2ft Med. Bi-Pin 24.5” 1.5”
3ft Med. Bi-Pin 36.5” 1.5”
4ft Med. Bi-Pin 48.5” 1.5”
9
