Kino Flo Image 82, 42 & 22 - Manual (Page 3)

Insert lamps into both lamp connectors. Twist ¼ turn to make
electrical contact.
The gel frame is secured to the fixture by 4 spring-loaded pins. Align the
pins of the gel frame with the oval receptacle holes on the edge of the
fixture. Pull back the pins and release into the receptacles to properly
secure the gel frame.
3
(A) (B) A) The Gel Frame comes with
Gel Clips. Cut the gel to size and
use the Clips to fasten the gel to
the Frame.
B) Another method is to apply
transfer tape directly to the gel
frame. The clips are not
necessary when taping the gel.
