10
Kas-I80-1 Kas-I80-2 KAS-48
Part Description Dimensions Weight Holds
Number (Empty)
KAS-I80-2 Image 82 Ship Case 56.25” x 16.25” x 35” 98 lb / 44Kg Image 82 x 2
1435mm x 413mm x 889mm
8KAS-I80-1 Image 82 Ship Case 56.5” x 7.75” x 35” 38lb / 17Kg Image 82 x 1
1435mm x 197mm x 889mm
KAS-I40-1 Image 42 Ship Case 56.5” x 10.25” x 23.25” 29lb / 13Kg Image 42 x 1
1435mm x 260mm x 590mm
KAS-I20-1 Image 22 Ship Case 31.25” x 10.25” x 23.25” 18lb / 8Kg Image 22 x 1
794mm x 260mm x 590mm
KAS-48 4ft Lamp Ship Case 52.5” x 10.5” x 11.25” 15lb / 7Kg 4ft T12 Lamps(20)
1333mm x 267mm x 286mm
Model: Image 82
Power requirements: 120VAC or 230VAC
Amperage: 10 amps at 120VAC, 5 amps at 230VAC
Weight w/lamps: 37lb / 16.7Kg
Dimensions: 54.5” x 32.63” x 6.25”
1384mm x 829mm x 159mm
Lamp Switching: 8 / 6 / 4 / 2 / Off
Lamp types: F40T12
