Adjust the hinge tension with a Phillips head screwdriver.
Hinge Tension Adjustment
7
Imara Yoke Mount
The Yoke has a ½” hole to accept industry standard mounting hardware.
The Imara S10 and S6 Yoke Mount can mount to a stand or hang from a
studio grid via a standard junior pin or Junior Pin Assembly for Yoke (MTP-I80),
sold separately.
Note: Loop the safety chain around the yoke.
The Yoke Mount is also designed with
two holes to allow the yoke bracket
to be placed in one of two positions.
The additional option is useful when
hanging the units in a studio with a
low ceiling.
Warning: Use only M5 X 10mm screws (supplied) to mount yoke. Note that
threads on the fixture are self-locking and may seem tight. Replacement screws:
Part No. 2020127
Recommended torque setting:
USA: 18 lb-in
Metric: 2 Nm
MTP-I80
