Kino Flo Diva-Lite 401/201 & 400U User Manual
Page 7
7
Inserting/ Removing Lamps
Applying Gel Frame and Louver
To insert, position lamp
over lamp holder.
To remove, press red
locking tab down and
pull up on lamp.
The Gel Frame is held to the fixture with 4 Velcro straps.
The Louver is fastened to the fixture with 4 Velcro straps.
Press lamp base down
until it clicks into place.
Pull lamp out of lamp
clip.
Press lamp end into lamp
clip.
Warning!
Do Not lubricate the
sliding lock mechanism
on the lamp holder.
