Kino Flo Celeb 400 DMX LED - Manual (Page 5)

5
Fixture Power
DC Input
The Celeb can also be operated on 24VDC (input range 18-28VDC) through
a 3-Pin XLR. A low voltage warning will display “ LPWR” when the battery is
running low.
The pin polarity is:
Pin #1 – Ground
Pin #2 + 18-28VDC
Pin #3 not used
AC Input
The Celeb is powered AC and includes an IEC connection. A locking
power cord is included with the fixture. To remove the plug, move the red tab
to release. The ballast has a built-in power supply with universal input from
100-240VAC.
Ambient Operating Temperature
The Celeb is designed to operate at temperatures from 14°F to 104°F
(-10°C to 40°C).
