Mounting
Align center pin of
mounting plate (MTP-BL41)
with mating receptacle on
fixture.
Align locking pin with the
yellow arrow.
Rotate mount plate in direction of the small
arrow. The locking pin will snap into place.
The safety wire loop provides an attachment
point for a safety chain if fixture is hung from
a grid.
A 180° turn loosens the orientation of the mount.
A right turn tightens the mount.
The tension on the lock lever may be adjusted
by pulling the handle away from the mount.
This disengages the handle from the screw
mechanism and allows the lever to be reori-
ented.
6
To remove the plate, pull up on the locking pin
and reverse the mounting procedure.
