2
Getting to Know Your RemoteMix 3.5
6 7 11 10 8
9
2 3 4 1
5
1.
Mic Level Controls
Each of the three XLR inputs has a level control knob with a separate red
LED to indicate clipping on each channel. If you see more than an
occasional flash of the LED you should decrease the level for that
channel.
2.
Master Level Control
The control knob will set the overall level of the sum of all the mic
and line inputs. The LED meter for the master audio level ranges from -30
dB to +3 dB.
3. Keypad
The telephone keypad provides DTMF tone dialing. You may use the
keypad at anytime during a call but keep in mind that both transmit and
receive telephone audio are muted during a keypress.
4.
Redial
Press this button to instantly redial the last telephone number that was
keyed in.
5.
Headphone Controls
Each of the three headphone outputs has a separate level control so each
listener can adjust their audio level independently.
Controls & Indicators
RemoteMix 3.5™ Broadcast Field Mixer
