Technical information, Block diagram – JK Audio RemoteMix 3.5 User Manual
Page 16
12
Technical Information
Master
LED Meter
Limiter
Bluetooth
Handset
Jack
Universal Handset Interface
Phone Line Hybrid
DTMF Keypad
Phone Line
Headset Emulator
Return
Headphone Cue
Master Output
3.5 mm Stereo Output
Headphone
1
Headphone
3
Wireless Phone
Cue Input
Mic / Line
3.5 mm Line Input
XLR Input
1
XLR Input
2
XLR Input
3
Headphone
2
Block Diagram
RemoteMix 3.5™
Broadcast Field Mixer
