CLX (9/07) Page 1
REV 3.1
Specifications
Measurement Range 0 – 10.00 mg/L (PPM)
Accuracy ±5% or ±0.03 mg/L (PPM) for range of 0-6 mg/L(PPM)
Resolution 0.01 mg/L (PPM)
Cycle Time Adjustable: 90 seconds to 10 minutes (defaults to 2.5 minutes)
Display Multi-Line Liquid Crystal Backlit Display
Alarms Two Programmable, 120-240VAC 2A Form C Relay
Analog Output Powered 4-20 mA, 600
Ω drive, isolated
Communications Port Bi-directional RS-485 with Modbus
Maximum Water Pressure Integral pressure regulator rated 1380kPa (200 PSI.)
Flow Rate 200 ml/min. minimum flow
Operating Temperature 5°C – 40°C (41°F – 104°F)
Wetted Materials Nylon, Borosilicate Glass, Silicon, Polypropylene, Stainless Steel, Brass
Sample Temperature Range 5°C – 40°C (41°F – 104°F)
Power Supply 100 – 240 VAC, 47 – 63 Hz, 150VA
Insulation Rating Double Insulated, Pollution Degree 2, Overvoltage Category II
Environmental Conditions Not recommended for outdoor use.
Altitude up to 2000 meters
Up to 95 % RH (non-condensing)
Enclosure Rating Designed to meet IP 66 /NEMA 4X
Regulatory Compliance
And Certifications
CE Approved, ETL listed to UL 3111-1 &
ETL Certified to CSA 22.2 No. 1010-1-92
Shipping Weight 2.5 kg (5.5 lbs.)
Shipping Dimensions 406 mm X 406 mm X 229 mm (16”X 16” X 9”)
Warranty 1 Year from date of shipment
