Owner’s manual and assembly instructions: model 450000 outdoor patio heater 1/15/03
Contact 1-800-762-1142 for assistance.
Do not return to place of purchase.
Step 16 – Replace Engine Access Panel
• Slide Igniter wire onto Igniter post.
• Slide tab at top of Access Panel into slot in Emitter bottom.
• Rotate Panel down until holes line up at bottom.
• Secure Access Panel in place with thumbscrew.
• Replace Control Knob.
Step 18 – Install Igniter Battery
• Remove battery cover cap by turning cap counterclockwise.
• Install (1) AA battery. Negative end of battery goes in first.
• Replace battery cover cap by turning cap clockwise.
Note: Once you have successfully completed assembly steps 1-18 you
are ready to begin operating your heater.
Step 17 – Install Cylinder Access Door
• Line up tabs in bottom door panel with slots in base and insert.
• Rotate top of door until it rests against corner column rails.
• Rotate thumbscrew counterclockwise until it stops.
