GBC 25e - Manual (Page 40)

© 2002 IBICO
Operations Manual
Page 9-8 Patriot 25E
MANUFACTURE OR FOR ANY OTHER PURPOSE WITHOUT WRITTEN
COPIED OR DISCLOSED IN WHOLE OR IN PART, OR USED FOR
FOR ENGINEERING INFORMATION ONLY AND SHALL NOT BE REPRODUCED,
GBC PRO-TECH CLAIMS PROPRIETARY RIGHTS TO THE
MATERIAL DISCLOSED ON THIS DRAWING. IT IS ISSUED IN CONFIDENCE
PERMISSION FROM GBC PRO-TECH
PROPRIETARY
C
GBC Films Group
4151 Anderson Road, DeForest, WI 53532
This print is the property of GBC Films Group. The information thereon is remitted in confidence.
UNLESS OTHERWISE SPECIFIED
TOLERANCE
DIM. AS
SHOWN TOL.
+ 1/64
+ .050
+ .020
+ .010
+ .005
X/X
X
XX
XXX
XXXX
ANGLES
+ 1D
FINISH
TO BE
125
TITLE :
DATE : DRAWN BY : DWG SCALE : DWG :
R
E VI
SI
O
N
CH
E C
K E D B
Y : G
BC
F IL
M S
G
R O
U P
Assembly, frame
Patriot 25E
P25E-005 N/A NSG 07/01/02
(1)706111121
Back Trimmer Assy.
(1)613030151
Tie Bar
(1)610010211
120V Transformer
(1)604036135
Back Trimmer Assy.
(1)601230112
(1)705200201
Infrared Sensor
(1)604036136
Rear Cover, Lower
(1)7050703
(1)601250122
Side Plate (R)
(1)601250126
Sensor Bracket
(1)604036133
Front Base Plate (up)
(1)601220132
Front Base Plate (Low)
(4)703010111
Rubber Foot
(1)601250121
Side Plate (L)
