© 2002 IBICO Operations Manual
Patriot
25E
Page 9-7
MANUFACTURE OR FOR ANY OTHER PURPOSE WITHOUT WRITTEN
COPIED OR DISCLOSED IN WHOLE OR IN PART, OR USED FOR
FOR ENGINEERING INFORMATION ONLY AND SHALL NOT BE REPRODUCED,
GBC PRO-TECH CLAIMS PROPRIETARY RIGHTS TO THE
MATERIAL DISCLOSED ON THIS DRAWING. IT IS ISSUED IN CONFIDENCE
PERMISSION FROM GBC PRO-TECH
PROPRIETARY
C
GBC Films Group
4151 Anderson Road, DeForest, WI 53532
This print is the property of GBC Films Group. The information thereon is remitted in confidence.
UNLESS OTHERWISE SPECIFIED
TOLERANCE
DIM. AS
SHOWN TOL.
+ 1/64
+ .050
+ .020
+ .010
+ .005
X/X
X
XX
XXX
XXXX
ANGLES
+ 1D
FINISH
TO BE
125
TITLE :
DATE : DRAWN BY : DWG SCALE : DWG :
R E VI
SI
O N
CH
E C K
E D BY
: G
B C F
IL
M
S G
R O U
P
Assembly, Cover And Film Shaft
Patriot 25E
P25E-004 N/A NSG 07/01/02
(4) 613030527
Core Bush Bolt
(2) 613030301
Film Shaft Bushing
(2) 613030211
Film Shaft
(4) 604037021
1in. Core
(1) 601230453
Roller Cover
(1) 604036131
Film Guide Screen
(1) 604036137
Roll Cover Cap
(1) 613030612
Cover Support Pin
(1) 701090844
Spring Pin
