Operations Manual Patriot 25E
Page 9-1
9.0 Illustrated Parts
WARNING: Illustrated parts drawings are to be
used only for ordering parts. They should not be used
to perform repair work yourself. Contact your local
service representative for service.
The parts list is in muneric order. The parts illustration are
in assembly order. If a part you rquire does not exist in
the parts list or in the parts illustration section, contact
you local service representative for assistance.
INFORMATION: The numeric value in the ( ),
represent quanity per machine, not per assembly.
9.1 Parts list
Part # Item Description QTY Unit
601230453 Roller cover 1 EA
601230521 Infrared heater support 2 EA
601230702 Inner tension panel 2 EA
601230802 Film shaft support panel 2 EA
601230804 Idler housing 1 EA
601250121 Side plate (L) 1 EA
601250122 Side plate (R) 1 EA
601250123 Film tension lever 2 EA
601250124 Power panel 1 EA
601250125 Circuit breaker support 1 EA
601250126 Sensor bracket 1 EA
601310501 Infrared heater inner support (N) 2 EA
601310504 Idler gear support 1 EA
601310508 Micro-switch support bracket 1 EA
601310509 P/R tension lever (L) 1 EA
601310510 P/R tension lever (R) 1 EA
601310511 Front lever fixing panel 1 EA
601310512 Tension adjustment panel 2 EA
601310521 Infrared heater outer support (N) 2 EA
604022032 Paper guide knob 2 EA
604022106 Paper guide 1 EA
604022111 Side cover (L) 1 EA
604022112 Side cover (R) 1 EA
604036131 Film guide screen (UP) 1 EA
604036133 Front base plate 1 EA
