Bowers & Wilkins CWM200 - Manual (Page 14)

I
4987
Drive units
Frequency response
Sensitivity
Nominal impedance
Crossover frequency
Recommended
amplifier power
Frame size
Cut-out size
Min depth required
Net weight
Finishes
1x 25mm (1in) high-frequency
1x165mm (6.5in) mid/bass
50Hz – 20kHz ±3dB
89dB spl (2.83V, 1m)
8Ω
3.5kHz
20W – 130W continuous into 8Ω
on unclipped programme.
Height : 306mm(12in)
Width : 219mm(8.6in)
Height : 283mm(11.1in)
Width : 196mm(7.7in)
73mm (2.9in) from wall surface
1.3kg (2.9lb)
Semi-matt white suitable for
customising or pre-painting
CWM200
B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments. E&OE
Copyright © B&W Loudspeakers Ltd. Printed in Taiwan.
B&W Loudspeakers Ltd, Meadow Road, Worthing, BN11 2RX, England
Tel: +44 (0) 1903 524801 Fax: +44 (0) 1903 524725
http://www.bwspeakers.com
