TROUBLESHOOTING -
TL2900
SPECIFICATIONS -
TL2900
26
Problem
No power
LED’s say redo
Element is not closing
Crimp quality is poor
Wire elements are tangled coming out of the box
Element is not closing fully or to much
Wire seam is in the front
Power cord has been lost
Solution
Check to make sure unit is plugged in
Press and hold the bind buttons for one full second
Check wire size selection
A. Check quality of different size wire
B. Check condition of hooks, if necessary install a new hook as
described in the unpacking and setup section of this manual,
Hook replacement kit P/N 7301340, 2 per kit
Drop them on a table top and they will untangle
Fine tune the knob as more or less as needed
Bind the book with the seam between the back cover and last page
Contact an authorized GBC Technician, order replacement part
P/N 6200001 115V North America
P/N 6200002 230V Europe
P/N 6200014 230V United Kingdom
P/N 6200016 240V Australia
P/N 6200017 100V Japan
*Subtract 8-10 pages from sheet capacity when adding covers.
Maximum
Maximum Sheet
Twin Loop
Twin Loop
Loops per
Book
Capacity using
Wire Size
Wire Size
Inch
Thickness
20# paper*
3/16"
46
1/4''
6 mm
Three
1/4''
62
5/16"
8 mm
Three
5/16"
78
3/8"
10 mm
Three
3/8"
93
7/16"
11 mm
Three
7/16"
109
1/2''
13 mm
Three
1/2''
125
9/16"
14 mm
Three
9/16"
140
5/8"
16 mm
Two
5/8"
156
3/4''
20 mm
Two
3/4''
187
7/8"
22 mm
Two
7/8"
218
1"
25 mm
Two
1-1/8"
250
1-1/4"
32 mm
Two
TWIN LOOP SIZE CHART (A1)
Dimensions
18" W; 7" H; 13" D
Weight
43 lb.
Packaged Weight
51 lb.
Electrical
115V; 60Hz; 3.5 Amps
230V; 50Hz; 1.0Amps
