E-flite C-Ray 180 PNP User Manual

Page 3

hank you for purchasing the exciting new E-ﬂ ite

ﬂ ying wing, the C-Ray 180 PNP. Constructed of

durable Z-Foam

™

material, this agile little ﬂ ying wing is designed to bounce back from mild impacts time

and time again. The perfect airplane for parks and small ﬂ ying areas, the C-Ray

™

airplane delivers snappy,

fast and fun performance that intermediate through expert pilots will love. With its included decal sheet,
personalizing your C-Ray airplane is easy so you can distinguish which airplane is yours when ﬂ ying with
buddies.

Although this great ﬂ ying plane requires very little assembly out of the box, we encourage you to take a little
time to absorb the content of this manual before your ﬁ rst ﬂ ight. Inside you’ll ﬁ nd helpful setup tips, a handy
troubleshooting guide and guidelines to help you select appropriate ﬂ ying ﬁ elds for this model, as well as
important safety considerations.

To register your product online, go to
www.e-ﬂ iterc.com

Table of Contents

Installed

180 Brushless Outrunner Motor, 2500Kv
(EFLM7005)

8-Amp Brushless ESC (EFLA7200)

(2) 3 g Super Sub-Micro Servo
(EFLR7105)

Needed to Complete

Recommended Battery: 450mAh 2S
7.4V 30C Li-Po, 18AWG JST
(EFLB4502SJ30)

Recommended Battery Charger:
Celectra

™

80W AC/DC Multi-Chemistry

Battery Charger (EFLC3025)

Recommended Receiver: Spektrum

™

AR6310 DSMX Nanolite 6-Channel
Receiver, Air (SPMAR6310)

Recommended Transmitter:

Full Range

DSM2

/DSMX

technology with adjust-

able dual rate, expotential and elevon
mixing (DX6i and up)

4.40 oz
(125 g)

Box Contents

Preﬂ ight Checklist ................................................. 4
Battery Selection .................................................. 4
Low Voltage Cutoff (LVC) ....................................... 4
Installing a Receiver .............................................. 5
Installing the Flight Battery .................................. 6
Arming the ESC .................................................... 7
Control Horn and Servo Arm Settings .................... 7
Transmitter and Model Setup ................................ 8
Control Direction Test ........................................... 9
Control Centering ................................................. 9
Adjusting the Center of Gravity (CG) .................... 10

Applying Decals .................................................. 10
Flying Tips and Repairs ....................................... 11
Post Flight Checklist ........................................... 11
Service of Power Components ............................ 12
Troubleshooting Guide ........................................ 13
Limited Warranty ................................................ 14
Warranty and Service Information ....................... 15
Compliance Information for the European Union .. 15
Replacement Parts .............................................. 58
Optional Parts and Accessories ........................... 59
Parts Contact Information ................................... 59

Speciﬁ cations

13.5 in (342mm)

21.7 in (550mm)
