Transmitter Specific Binding Instructions
DX6i:
A. Select a new model memory or the chosen model memory that you want for
the 4-Site.
B. To bind your 4-Site to the DX6i, plug the battery into the receiver of the airplane.
The LED on the receiver will begin flashing.
C. Move the sticks and switches on the transmitter to the desired failsafe positions
(low throttle and neutral control positions).
D. Pull and hold the Trainer Switch on the transmitter while turning the transmitter on.
Release the trainer switch once the word BIND flashes on the LCD screen on the
front of the transmitter.
E. The LED on the receiver will go solid red and the system will connect after
several seconds.
DX7 (includes DX7se):
A. Select a new model memory or the chosen model memory that you want for
the 4-Site.
B. To bind your 4-Site to the DX7, plug the battery into the receiver of the airplane.
The LED on the receiver will begin flashing.
C. Move the sticks and switches on the transmitter to the desired failsafe positions
(low throttle and neutral control positions).
D. Press the bind button on the back of the transmitter while turning the transmitter
on. The bind button on the back of the transmitter will flash. Release the button
after 2–3 seconds.
E. The LED on the receiver will go solid red and the system will connect after
several seconds.
X9303:
A. Select a new model memory or the chosen model memory that you want for the
4-Site.
B. To bind your 4-Site to the X9303, plug the battery into the receiver of the airplane.
The LED on the receiver will begin flashing.
C. Move the sticks and switches on the transmitter to the desired failsafe positions
(low throttle and neutral control positions).
D. Press the bind button on the back of the transmitter while turning the transmitter
on. The bind button on the back of the transmitter will flash. Release the button
after 2–3 seconds.
E. The LED on the receiver will go solid red and the system will connect after several
seconds.
12X:
A. Start with a blank model memory, or the one you have selected for the 4-Site.
B. To bind your 4-Site to the 12X, plug the battery into the receiver of the airplane.
The LED on the receiver will begin flashing.
C. Move the sticks and switches on the transmitter to the desired failsafe positions
(low throttle and neutral control positions).
D. Press the black bind button on the back of the transmitter while turning the
transmitter on. Release the button after 2–3 seconds.
E. The LED on the receiver will go solid amber and the system will connect after
several seconds.
Note: Before each flight, you should ALWAYS turn the transmitter on before
connecting the flight battery to the receiver unit. After each flight, be sure
that you always disconnect the flight battery from the receiver unit before
powering the transmitter off.
Additional Binding Information
Prior to each flight, you should ensure that you power on your transmitter and wait
about five seconds before you plug the flight battery into the receiver. Doing this
allows time for the transmitter to scan and secure two open frequencies. If the flight
battery is plugged in too quickly and the link is missed, it may cause the receiver to
inadvertently enter bind mode. If this occurs simply leave the transmitter on and then
disconnect and reconnect the flight battery.
