sPACe
Model No. desCRiPTioN PiPe siZe ReQUiRed WeiGHT
W x d x H lBs KGs
PWS10111A11 1 Cubic Foot Simplex Softener with Flow Meter 1" 18" x 32" x 59" 116 53
PWS10111B11 1.5 Cubic Foot Simplex Softener with Flow Meter 1" 18" x 33" x 65" 136 62
PWS10111C11 2 Cubic Foot Simplex Softener with Flow Meter 1" 18" x 35" x 63" 196 89
PWS10111D11 3 Cubic Foot Simplex Softener with Flow Meter 1" 18" x 40" x 76" 240 109
PWS10111E11 4 Cubic Foot Simplex Softener with Flow Meter 1" 18" x 40" x 76" 320 145
Notes: Capacities are based on resin manufacturer’s data and are dependent upon influent water TDS, temperature, bed depth, and
flow rates. Feed water must be free of oil and color. Pipe size, tank size, and space requirements are in inches. Flow rates listed at 25
psi drops are for intermittent peak flow rates and are not to be used as continuous flows.
ES-WQ-PWS10 1136 © 2011 Watts
USA: North Andover, MA • Tel. (800) 224-1299 • www.watts.com
Canada: Burlington, ON • Tel. (888) 208-8927 • www.wattscanada.ca
A Watts Water Technologies Company
Specifications
MiNeRAl TANK BRiNe TANK soFTeNiNG lBs. sAlT PeR FloW RATe & PRessURe
TANK ResiN GRAVel TANK sAlT CAPACiTY ReGeNeRATioN seRV dRoP BKW
Model No. siZe Ft 3 siZe Fill MAx MiN MAx MiN GPM Psi GPM
PWS10111A11 9" x 48" 1.0 10 lbs. 18" x 40" 400 30 K 20 K 15 6 9/15 15/25 2.0
PWS10111B11 10" x 54" 1.5 10 lbs. 18" x 40" 400 45 K 30 K 22.5 9 10/15 15/25 2.4
PWS10111C11 12" x 52" 2.0 30 lbs. 18" x 40" 400 60 K 40 K 30 12 15/20 15/25 3.5
PWS10111D11 14" x 65" 3.0 60 lbs. 18" x 40" 400 90 K 60 K 45 18 18/23 15/25 5.0
PWS10111E11 16" x 65" 4.0 80 lbs. 18" x 40" 400 120 K 80 K 60 24 19/25 15/25 7.0
Ordering Information
Note: This information is not intended to replace the product
installation and safety information available or the experience of
a trained product installer. Please refer to the product installa-
tion and safety instructions for further information.
