For Commercial Applications

ES-WQ-PWC

Job Name –––––––––––––––––––––––––––––––––––––––––––

Contractor ––––––––––––––––––––––––––––––––––––––––––––

Job Location –––––––––––––––––––––––––––––––––––––––––

Approval –––––––––––––––––––––––––––––––––––––––––––––

Engineer –––––––––––––––––––––––––––––––––––––––––––––

Contractor’s P.O. No. ––––––––––––––––––––––––––––––––––

Approval –––––––––––––––––––––––––––––––––––––––––––––

Representative ––––––––––––––––––––––––––––––––––––––––

Series

PWC10

Series

PWC15

Series

PWC20

Series

PWC30

Series PWC

Commercial Carbon Filter Systems

Connection Sizes: 1" to 3" (25 - 80mm)

Flow Rates: Up to 129 gpm (488 lpm)

Watts Pure Water Series PWC activated carbon filters are

highly effective backwashing media filtration systems for the

removal of chlorine as well as taste, odor, and color caused by

organics, from water.
They are suitable for commercial applications with dechlorina-

tion flow rates up to 129 gpm (488 lpm) with media bed sizes

ranging from 1 to 35 cubic feet in size. If higher flow rates are

required, multiple units can be installed in parallel. The media

bed is cleaned of captured sediment by periodic backwash-

ing and flushing. This cleaning cycle is time clock demand

initiated and can be programmed to occur at any time that is

convenient for the user. All steps of the cleaning cycle as well

as returning to service are fully automatic and do not require

manual actuation.
Watts Pure Water Series PWC activated carbon filters are

designed for point of use or point of entry applications where

dechlorinated water is required. Chlorine, an oxidizing agent,

is added to municipal water to destroy micro-organisms.

Chlorine causes the destruction of reverse osmosis mem-

branes and polymer based ion exchange resins. Chlorine also

causes objectionable tastes and odors in certain applications.

Activated carbon in general is used for dechlorination, removal

of taste, color, and odor caused by organics, as well as trace

hydrocarbon removal from water. For applications involving

trace hydrocarbon removal or taste, color, and odor removal

due to organics, consult your Watts representative for proper

sizing and carbon system selection. Watts Series PWC acti-

vated carbon filters utilize 12x40 mesh coconut shell carbon

granules which are tailored for chlorine removal. Coconut shell

carbon media has a high micro-porosity which makes it ideally

suited for the removal of low molecular weight contaminants

such as chlorine. Another advantage of this carbon is its supe-

rior hardness, which combined with a de-dusting process in

its production, creates an exceptionally clean product with low

fines.
These systems are ideal for food and bottled water processing,

restaurant drink station water treatment, commercial ice pro-

duction, soft drink water processing, reverse osmosis pretreat-

ment, ion exchange resin pretreatment, and general dechlori-

nation of municipal water.

Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements,
please contact Watts Technical Service. Watts reserves the right to change or modify product design, construction, specifications, or materials with-
out prior notice and without incurring any obligation to make such changes and modifications on Watts products previously or subsequently sold.

Features

• WQA Certified fully automatic time clock initiated control valve
• Sophisticated digital electronic controls that store operating

history that can be accessed by the user

• Fully adjustable backwash and flush cycles
• Durable brass bodied control valve for years of service
• Dry contact lock out switch for remote interface is standard
• High surface area, with a minimum of 1,050 m²/g, low carbon

fines, and coconut shell carbon

• Highly corrosion resistant NSF Certified fiberglass tanks
• Durable polypropylene lower distribution system

Standards

Control Valve- WQA Certified to NSF/ANSI Std. 61

Mineral Tank- NSF Certified to ANSI Std. 44 or 61

PURE WATER

Note:

Do not use with water that is microbiologically unsafe or

of unknown quality without adequate disinfection before or after

the system.
