DUAL A/B SWITCH AB200
Fig. 2.3: Two instruments / two amps
Two AB200 channels are needed for this application: plug
each instrument into one of the A1 and B1 connectors and each
amp input into one of the A2 and B2 connectors. Link IN/OUT 1
and IN/OUT 2 plugs using a short cable. Pressing the switch 1
toggles between the two instruments while pressing the switch
2 toggles between the two amps.
3. WARRANTY
For our current warranty terms and conditions, please refer to
our website at http://www.behringer.com.
4. SPECIFICATIONS
In 1, In 2, Out A, Out B
Connector 1/4" TS
Impedance relais hard bypass
Battery 9 V type 6LR61
Power consumption <30 mA
Dimensions (H x W x D) approx. 46 mm (1 4/5")
x 14 mm (5 1/4")
x 89 mm (3 1/2")
Weight approx. 0.28 kg (0.62 lbs)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result
of these efforts, modifications may be made from time to time to existing products without prior
notice. Specifications and appearance may therefore differ from those listed or shown.
5. SAFETY INSTRUCTIONS
Do not use near water, or install near heat sources. Use only authorized
attachments/accessories. Do not service product yourself. Contact our
qualified servicing personnel for servicing or repairs.
No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo
accesorios y aditamentos autorizados. No intenté reparar el producto usted
mismo. Contacte a nuestro personal técnico cualificado para servicio y
reparaciones.
Не эксплуатируйте прибор вблизи от источников воды и тепла.
Применяйте только авторизованные дополнительные устройства.
Никогда не ремонтируйте прибор самостоятельно. Ремонт может
производить только квалифицированный специализированный
персонал.
Ne pas utiliser ni installer à proximité de liquide ou de sources de chaleur.
Utilisez exclusivement les accessoires autorisés. Ne réalisez pas de
maintenance vous-même sur le produit. Contactez notre personnel technique
pour tout service ou réparation.
Betreibe das Gerät nicht in der Nähe von Wasser oder Wärmequellen.
Verwende bitte nur autorisiertes Zubehör. Führe bitte keinerlei Reparaturen
am Gerät eigenständig durch. Reparaturen sind nur von qualifiziertem
Fachpersonal vorzunehmen.
Non usare in prossimità dell’acqua o installare vicino a fonti di calore.
Usare solo collegamenti ed accessori approvati. Non tentare di riparare
l’apparecchio da sé. Contattare il nostro personale specializzato per eseguire
operazioni di manutenzione e riparazione.
Niet gebruiken in de buurt van water of warmtebronnen. Gebruik uitsluitend
geautoriseerde uitbreidingen/originele accessoires. Probeer nooit zelf het
apparaat te repareren. Neem voor reparaties of onderhoud contact op met
de leverancier.
Nie u¿ywaæ w pobli¿u wody ani nie instalowaæ w pobli¿u Ÿróde³ ciep³a.
Stosowaæ wy³¹cznie dodatki/akcesoria dopuszczone przez producenta. Nie
naprawiaæ urz¹dzenia samodzielnie. Serwisowanie i naprawy zlecaæ naszemu
wykwalifikowanego personelowi.
Älä käytä laitetta veden tai lämmönlähteiden lähellä. Käytä vain
hyväksyttyjä lisätarvikkeita. Älä tee laitteeseen itse minkäänlaisia
korjauksia. Ainoastaan pätevä ammattihenkilökunta saa suorittaa
korjaukset; tämä koskee.
Må ikke anvendes i nærheden af vand eller installeres i nærheden af
varmeenheder. Brug kun godkendte tilslutninger/tilbehør. Forsøg ikke selv
at reparere produktet. Kontakt vores kvalificerede servicepersonale for at
få udført service og reparation.
Får inte användas i närheten av vatten eller installeras nära värmekällor. Använd
endast godkända delar/tillbehör. Utför aldrig själv någon service på produkten.
Kontakta vår kvalificerade servicepersonal för service eller reparationer.
Não utilize na proximidade de água, nem instale perto de fontes de calor.
Use apenas conexões e acessórios autorizados. Não repare o seu produto.
Contacte o nosso pessoal qualificado para consertos ou reparações.
Мз чсзуймпрпйеЯфе фз ухукехЮ кпнфЬ уе несь кбй мзн фзн егкбийуфЬфе кпнфЬ уе
рзгЭт иесмьфзфбт. ЧсзуймпрпйеЯфе мьнп егкексймЭнб еобсфЮмбфб/рбселкьменб.
Мзн екфелеЯфе пй Ядйпй есгбуЯет уЭсвйт. Гйб фзн екфЭлеуз есгбуйюн уЭсвйт Ю
ерйукехЮт, ерйкпйнщнЮуфе ме фп ейдйкехмЭнп рспущрйкь уЭсвйт фзт ефбйсеЯбт мбт.
Technical specifications and appearance subject to change without notice.
The information contained herein is correct at the time of printing. The
names of companies, institutions or publications pictured or mentioned and
their respective logos are registered trademarks of their respective owners.
Their use neither constitutes a claim of the trademarks by BEHRINGER ®
nor affiliation of the trademark owners with BEHRINGER ® . BEHRINGER ®
accepts no liability for any loss which may be suffered by any person who
relies either wholly or in part upon any description, photograph or statement
contained herein. Colours and specification may vary slightly from product.
Products are sold through our authorised dealers only. Distributors and
dealers are not agents of BEHRINGER ® and have absolutely no authority
to bind BEHRINGER ® by any express or implied undertaking or
representation. No part of this manual may be reproduced or transmitted in
any form or by any means, electronic or mechanical, including photocopying
and recording of any kind, for any purpose, without the express written
permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER ®
is a registered trademark. ALL RIGHTS RESERVED. © 2005 BEHRINGER
Spezielle Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877
Willich-Münchheide II, Germany. Tel. +49 2154 9206 0,
Fax +49 2154 9206 4903
