20
English
Mounting Your VS-2 on a Wall
Required tools
Recommended hardware
Install two screws eight inches apart.
Leave ¼ inch (6 mm) between wall
surface and screw head.
Position the VS-2 mounting holes over the
screws so that it is flush with the wall. Lower the VS-2 onto the screws
to lock it in place.
1
2 3
For solid wood
For wallboard
-inch (3.5 mm) drill bit 1 8
Use drill size
specified for type
of wall anchor
used.
No. 8 x 1½-inch
(M4 x 36 mm)
wood screws
No. 8 x 1½-inch (M4 x 36 mm)
wood or machine screws (depends
on type of wall anchor)
No. 8 (M4)
wall anchor
