3 Installation
851 Titrando
￭￭￭￭￭￭￭￭ 27
Screwing on the electrode cable
Screw on the electrode cable as follows:
1 Unscrew the cover of the indicator electrode.
1
Figure 15 Unscrewing the cover from the indicator electrode
2 Unscrew the cover of the generator electrode.
1
Figure 16 Unscrewing the cover from the generator electrode
3 Tighten the 6.2104.020 electrode cable to the indicator electrode.
4 Tighten the 6.2104.120 electrode cable to the generator electrode.
