33
READ THIS MANUAL IN ITS ENTIRETY PRIOR TO USING THIS PRODUCT.
This Instruction Manual complies with the Treestand Manufacturers Association’s
TMS 04 - Standard Practice for Treestand Instructions & TMS 02 - Standard Test Method for Treestand Fall Arrest Systems
STEP 10. Assemble the rail by sleeving the rear rails into the front rails and
secure using (2) 1/4" x 1 1/4" hex bolts [J] and (2) 1/4" nylock nuts. Next insert
the rail connector into each end of the front rails, aligning holes. (fig. 4)
STEP 11. Attach the assembled rail to the outside of the (4) rail supports and the (2)
rear rail supports using (6) 5/16" x 2" hex bolts [G] and (6) 5/16" nylock nuts. (fig. 4)
STEP 12. SECURELY TIGHTEN EVERY NUT AND BOLT AT THIS TIME.
STEP 13. Attach shooting rail cover, seat cushion and backrest cushion. (fig. 4)
To activate your product’s warranty, a registration card can be found on page 103
and must be completed and returned to the manufacturer within 30 days of purchase.
Be sure to keep a copy of this for your records.
TOOLS REQUIRED FOR ASSEMBLY Adjustable Wrench qty 2
Min. Tree Diameter • 9 Inches # Person(s) • oNE (1)
Max.Weight Capacity (user and equipment) • 300 lb/136 kg
CR3901-S
SPECIFICATIONS
Part # Description Qty
UP11-0155 S - Top Ladder Section 1
UP10-0172 S - Middle Ladder Section 1
UP10-0173 S - Bottom Ladder Section 1
UP11-0006 Left foot Platform 1
UP11-0007 Right foot Platform 1
UP11-0008 Left outer foot Platform 1
UP11-0009 Right outer foot Platform 1
UP10-0195 Platform Support 1
UP11-0010 Platform Gusset 2
UP11-0011 Backrest 1
UP10-0051 Backrest Cushion 1
UP11-0013 Seat frame 1
UP11-0014 Seat Cushion 1
UP11-0015 Seat Post 1
UP11-0016 Seat Hub 1
UP10-0198 Right Under Support Gusset 1
UP10-0199 Left Under Support Gusset 1
UP10-0177 Support Bar - Ladder Piece 1
UP10-0336 Support Bar - Tree Piece 1
UP10-0123 foot Rest 1
UP10-0529 Rail Support 4
UP10-0530 Rear Rail Support 2
UP11-0017 front Rail 2
UP11-0018 Rear Rail 2
UP11-0019 Rail Connector 1
UP11-0020 Rail Cover 1
Part # Description Qty
UP10-0027 Ratchet Strap 1
UP10-0182 Rope 1
UP10-0183 Stabilizer Strap 2
UP10-0008 full Body Harness 1
UP10-0660 Treestand Safety DVD 1
UP12-0009 owners Manual 1
Hardware Pack 1
UP77-0021 [A] 1/4" x 1 3/4" Hex Bolt 3
UP77-0027 [B] 1/4" x 3" Hex Bolt 4
UP77-0035 [C] 5/16" x 3/4" Hex Bolt 2
UP77-0036 [D] 5/16" x 1 1/4" Hex Bolt 4
UP77-0038 [E] 5/16" x 1 1/2" Hex Bolt 12
UP77-0039 [f] 5/16" x 1 3/4" Hex Bolt 2
UP77-0041 [G] 5/16" x 2" Hex Bolt 4
UP77-0044 [H] 5/16" x 2 1/4" Hex Bolt 6
UP77-0043 [I] 5/16" x 2 1/2" Hex Bolt 4
UP77-0018 [j] 1/4" x 1 1/4" Hex Bolt 2
UP77-0024 [K] 1/4" x 2 1/4" Hex Bolt 2
UP77-0025 [L] 1/4" x 2 1/2" Hex Bolt 3
UP77-0030 5/16" Nylon Washer 4
UP77-0064 4" Nylon Washer 2
UP77-0001 1/4" Nylock Nut 13
UP77-0029 5/16" Nylock Nut 32
UP77-0065 Snap Pin 5
UP77-0006 1/4" Wing Nut 1
Parts List (CR3901-S)
