Model 436 – Bolens 436 User Manual
Page 17
17
Ref.
No.
Part No.
Description
1.
747-1161A
Control Handle
2.
710-1205
Rope Guide
3.
720-0279
Handle Knob 1/4-20 Thd.
4.
710-1174
Curved Hd. Bolt 5/16-18 x 2"
5.
720-0284
Hand Knob
6.
749-1092A
Upper Handle
7.
749-0928A
Lower Handle
8.
726-0240
Cable Tie
9.
747-04080
Grass Catcher Frame
10.
746-1130
Control Cable
11.
664-04007
Grass Bag
12.
714-0104
Int. Cotter Pin 5/16" Dia.
13.
732-04072
Door Spring - R.H.
14.
732-04071
Door Spring - L.H.
15.
731-04134
Rear Discharge Door
16.
732-1014
Torsion Spring
17.
747-0710
Hinge Pin
18.
732-0700
Wire Rod
19.
731-1236
Rear Flap
20.
748-0376C
Blade Adapter w/Star
21.
710-1044
Hex Bolt 3/8-24 x 1.5" Lg.
22.
736-0524A
Blade Bell Support
23.
17032A
Deflector Chute Adapter
24.
742-0741
21" Mulching Blade w/Star
25.
712-0431
Flange Nut 3/8-16 Thd.
26.
15261A
Height Adj. Plate
27.
15262B
Pivot Bar
28.
732-0404
Front Spring Lever
29.
738-0507B
Shld. Bolt.5" Dia. x.357"
30.
736-0105
Bell Washer.38" I.D. x.88" O.D.
31.
738-0102
Axle Bolt
32.
720-0426
Spring Lever Knob
33.
732-0417A
Rear Spring Lever
34.
14578
Height Adj. Assy. Comp. - RH
14579
Height Adj. Assy. Comp. - LH
35.
14765
Pivot Bar R.H.
14766
Pivot Bar L.H.
36.
782-5002A
Front Baffle
37.
710-0654A
Hex L-Wash.Scr. 3/8-16 x 1"
38.
782-5003
Rear Baffle - LH
39.
710-1017
Torx Mach AB-Tap Scr. 1/4 x.62"
40.
710-0896
HexIndWash. Scr. 1/4-14:.625
41.
787-01016
Handle Brkt. Ass’y.—RH
42.
787-01015
Handle Brkt. Ass’y.—LH
43.
787-01104
Deck 21”
44.
734-1987
Wheel Complete
45.
736-0270
Bell Washer 1/4" I.D.
46.
687-02055
Hinged Mulching Plug
47.
731-04177
Chute Deflector: Side Discharge
48.
710-0599
Hex Hd Self-Tp Scr. 1/4-20 x.5"
49.
782-5004A
Rear Baffle - RH
50.
710-0703
Hex Carriage Screw 1/4-20
51.
712-0397
Wing Nut
52.
750-04162
Spacer,.375OD x.50ID
53.
747-04035
Rear Door Pivot Rod
54.
736-0451
Shoulder Washer
Ref.
No.
Part No.
Description
Model 436
