PRO FC Installation and User’s Manual
3. Overview
3.1. The Bezel
The front bezel can be easily removed to access the Disk Modules. The bezel is
held on by four snap pins located at each of the four corners.
Use both hands, push from behind the left and right side of the bezel. Access
through the rack mount handles.
3.2. Disk Modules, Indicators, Controls, Connections
Disk Module
Power (white)
Activity (blue)
Key Lock
Page 11
PRO FC Installation and User’s Manual
Front view with bezel removed
Back view
Ports: Expander, FC, Ethernet Management
Status: Power, FC Activities, Fault, Alarm Reset, HDD, Ready
Power
Supply.
Optional
Dual
Redundant
Removable Cooling Fans
Mute Button, Fan Alarm, Temp Alarm
Drive Bays
